| Capacity | 1kVA to 20kVA Air Cooled |
|---|---|
| Input Voltage Range | 110-270V, 140-270V, 170-270V |
| System | 3 Wire (P,N+E) |
| Input Frequency | 47 to 53 Hz |
| Output Voltage Adjustable | 220 to 240V AC |
| Speed of Correction | Up to 60V/Sec |
| Output Voltage Regulation | ± 1% (No Load) |
| Ambient Temperature | 0 to 55 °C |
| Overload Capacity | 1.2 |
| Waveform Distortion | True Reproduction of Input |
| Insulation | Class F |
| Mode of System | Fully Automatic/Manual |
| Protection |
Low Voltage Protection, High Voltage Protection and Overload Protection,
Short-circuit Protection and power ON/OFF of SCVS through MCB at Input |
| Optional Features | Bypass switch at Input to bypass the equipment in case of emergency |
